| MODELO | 200WQ300-12-18.5 | 250WQ600-12-37 | 250WQ600-20-55 | 150WQ100-28-18.5 | 100WQ150-22-22 |
|---|---|---|---|---|---|
| CLAVE | 1130 | 1137 | 1139 | 1129 | 1131 |
| HP | 25 HP | 50 HP | 75 HP | 25 HP | 30 HP |
| W | 18500 W | 37000 W | 55000 W | 18500 W | 22000 W |
| Voltaje | 220V/440V~3F | 440V~3F | 440V~3F | 220V/440V~3F | 440V~3F |
| Frecuencia | 60 Hz | 60 Hz | 60 Hz | 60 Hz | 60 Hz |
| Flujo Máximo | 9000 (l/min) | 16300 (l/min) | 20000 (l/min) | 4500 (l/min) | 3590 (l/min) |
| Descarga Ø | 8" | 10" | 10" | 6" | 4" |
| Altura Máxima (Metros) | 25 m | 50 m | 75 m | 25 m | 30 m |
| Dimensiones (mm) | 670 x 570 x 1510 | 970 x 710 x 1850 | 970 x 710 x 1950 | 580 x 450 x 1320 | 580 x 450 x 1320 |
| Peso | 480 Kg | 1000 Kg | 1400 Kg | 380 Kg | 380 Kg |
