| MODELO | 100WQ100-22-15 | 150WQ200-12-15 | 150WQ150-22-22 | 200WQ250-17-22 | 150WQ150-36-30 |
|---|---|---|---|---|---|
| CLAVE | 1127 | 1128 | 1132 | 1133 | 1134 |
| HP | 20 HP | 20 HP | 30 HP | 30 HP | 40 HP |
| W | 15000 W | 15000 W | 22000 W | 22000 W | 30000 W |
| Voltaje | 220V/440V~3F | 220V/440V~3F | 440V~3F | 440V~3F | 440V~3F |
| Frecuencia | 60 Hz | 60 Hz | 60 Hz | 60 Hz | 60 Hz |
| Flujo Máximo | 3750 (l/min) | 5800 (l/min) | 6300 (l/min) | 9300 (l/min) | 9200 (l/min) |
| Descarga Ø | 4" | 6" | 6" | 8" | 6" |
| Altura Máxima (Metros) | 20 m | 20 m | 30 m | 30 m | 40 m |
| Dimensiones (mm) | 540 x 410 x 1210 | 560 x 500 x 1210 | 580 x 450 x 1320 | 670 x 570 x 1510 | 730 x 560 x 1740 |
| Peso | 280 Kg | 350 Kg | 380 Kg | 520 Kg | 800 Kg |
