| MODELO | 80WQ45-15-5.5 | 100WQ100-10-5.5 | 100WQ100-14-7.5 | 150WQ145-10-7.5 | 80WQ45-32-11 | 80WQ70-22-11 | 150WQ130-15-11 |
|---|---|---|---|---|---|---|---|
| CLAVE | 1120 | 1121 | 1122 | 1123 | 1124 | 1125 | 1126 |
| HP | 7 ½ HP | 7½ HP | 10 HP | 10 HP | 15 HP | 15 HP | 15 HP |
| W | 5500 W | 5500 W | 7500 W | 7500 W | 11000 W | 11000 W | 11000 W |
| Voltaje | 220V/440V~3F | 220V/440V~3F | 220V/440V~3F | 220V/440V~3F | 220V/440V~3F | 220V/440V~3F | 220V/440V~3F |
| Frecuencia | 60 Hz | 60 Hz | 60 Hz | 60 Hz | 60 Hz | 60 Hz | 60 Hz |
| Flujo Máximo | 2160 (l/min) | 2500 (l/min) | 1650 (l/min) | 4100 (l/min) | 3000 (l/min) | 3300 (l/min) | 5500 (l/min) |
| Descarga Ø | 3" | 4" | 4" | 6" | 3" | 3" | 6" |
| Altura Máxima (Metros) | 20 m | 18 m | 23 m | 19 m | 35 m | 30 m | 20 m |
| Dimensiones (mm) | 450 x 350 x 1030 | 450 x 350 x 1030 | 450 x 350 x 1030 | 570 x 450 x 950 | 500 x 400 x 1300 | 500 x 400 x 1300 | 650 x 520 x 1300 |
| Peso | 75 Kg | 80 Kg | 100 Kg | 170 Kg | 250 Kg | 250 Kg | 280 Kg |
