| MODELO | QDX5-10-0.37B | QDX10-10-0.55B | QDX15-10-0.75B | QDX6-16-0.75B |
|---|---|---|---|---|
| CLAVE | 1207 | 1208 | 1209 | 1210 |
| HP | 1/2 HP | 3/4 HP | 1 HP | 1 HP |
| W | 370 W | 550 W | 750 W | 750 W |
| Voltaje | 127 V~1F | 127 V~1F | 127 V~1F | 127 V~1F |
| Frecuencia | 60 Hz | 60 Hz | 60 Hz | 60 Hz |
| Flujo Máximo | 320 (l/min) | 350 (l/min) | 350 (l/min) | 360 (l/min) |
| Descarga Ø | 1.5" | 1.5" | 1.5" | 1.5" |
| Altura Máxima (Metros) | 12 m | 13 m | 15 m | 18 m |
| Flotador integrado | OPCIONAL | SÍ | OPCIONAL | OPCIONAL |
| Dimensiones (mm) | 170 x 220 x 360 | 170 x 220 x 360 | 170 x 220 x 390 | 170 x 220 x 390 |
| Peso | 8 Kg | 9 Kg | 10 Kg | 10 Kg |
